Optical Fiber Coupler, Single Wavelength, 1 x 2, 50/50, 633nm, FC/UPC
Optical Fiber Coupler, Single Wavelength, 1 x 2, 50/50, 633nm, FC/UPC
Model: F-CPL-S12635-FCUPC
Product Series Overview
1x2 and 2x2 Singlemode Fiber CouplersThe F-CPL-S12635 single wavelength optical fiber couplers allow bi-directional coupling and can be used to either split or combine signals. This 1x2 coupler with a 50/50 ratio provides optimal performance at a center wavelength of 633 nm in package type A. FC/UPC connector ends are standard. The F-CPL-S12635-FCUPC can be used directly with the 918D-IS-1 fiber optic detector. It can also be used with the 818 or 918D series detectors with the associated FP4-FC FC connector fiber adaptor and 818-FA connectorized fiber mount. See the Related Products tab for more information. Newport’s wide range of Optical Fiber Coupler products have been developed using fused fiber technology.
Resources & Downloads
Technical Notes
Drawings And Cad
Fiber pkg -A-S(65.2 kB, PDF)
Related Products
Similar
| Compare | Description | Drawings, CAD & Specs | Avail. | Price | ||
|---|---|---|---|---|---|---|
| F-CPL-S12635Optical Fiber Coupler, Single Wavelength, 1 x 2, 50/50, 633nm. | |||||
| F-CPL-S12635-FCAPCOptical Fiber Coupler, Single Wavelength, 1 x 2, 50/50, 633nm, FC/APC |
