Lasersmith Safety Goggles, 800 nm Diode and YAG Laser Wavelengths

The N-ML1-60 Safety Goggles are for 800 nm diode and YAG laser wavelengths. It has the Lasersmith Goggle frame with green color polycarbonate lenses. 45% VLT (visible light transmission). Lasersmith Goggles fit easily over prescription eyewear. It provides maximum comfort and airtight seal, with minimized fogging via ventilation. This model is CE certified. Meets ANSI Z136.1 and EN207.

Similar to Honeywell models 31-70162, G70108.

Specifications

Technical Specs

Frame Style
Lasersmith Goggle
Visible Light Transmission
45%
Filter Color
Green
Optical Density
OD5+ @ 190-420 nm
OD5+ @ 765-1100 nm
OD6+ @ 775-1085 nm
OD7+ @ 790-1080 nm

Lens Material
Polycarbonate
CE
Yes
EN207
190–315 nm (D LB8 + IR LB4)
>315–420 nm (DIR LB5)
>420–445 nm (DIR LB4)
765–1100 nm (DIRM LB5)
775–1085 nm (D LB5 + IRM LB6)
790–1080 nm (D LB6 + IRM LB7)
950–1085 nm (DIRM LB6)

Frame Style
Lasersmith Goggle
Visible Light Transmission
45%
Filter Color
Green
Optical Density
OD5+ @ 190-420 nm
OD5+ @ 765-1100 nm
OD6+ @ 775-1085 nm
OD7+ @ 790-1080 nm

Lens Material
Polycarbonate
CE
Yes
EN207
190–315 nm (D LB8 + IR LB4)
>315–420 nm (DIR LB5)
>420–445 nm (DIR LB4)
765–1100 nm (DIRM LB5)
775–1085 nm (D LB5 + IRM LB6)
790–1080 nm (D LB6 + IRM LB7)
950–1085 nm (DIRM LB6)
