Supercontinuum Generation Device, Femtosecond 800 nm Pulses

The SCG-800 Supercontinuum Fiber Device is a supercontinuum generation device for use with 800 nm femtosecond lasers. It contains 12 cm highly nonlinear, polarization maintaining photonic crystal fiber with zero dispersion at 750 nm, ideally designed for white light super continuum generation. The fiber ends are sealed and mounted in quartz ferrules, with their polarization axis aligned to a line on the end of the device. The nonlinear supercontinuum fiber is mounted in a robust, 25 mm diameter, 120 mm long aluminum housing, which can be easily mounted onto a translation stage. This white light generation device features built-in beam expansion at the end facets, facilitating easy coupling of the laser input beam and a higher damage threshold.
