XZ Linear Stage, Crossed-Roller, 25.4 mm Travel, M4, M6
The 9067-XZ-M Stainless Steel Crossed-Roller Translation Stage is a 25.4 mm travel linear translation stage that provides low-profile, high-stability, linear translation for systems that do not need vertical adjustment. 9067 series stages feature a generous pattern of twenty M4 and twenty one M6 threaded mounting holes. Actuators are not included. Please see specifications for recommended actuators.
Resources & Downloads
Drawings And Cad
9067-XZ(127 kB, PDF) 9067-XZa-Drawing.pdf(170.3 kB, PDF)
