Fiber Patch Cord, Multimode, F-MLD-C, 850/1300 nm, 1 m, FC Connectors
Fiber Patch Cord, Multimode, F-MLD-C, 850/1300 nm, 1 m, FC Connectors
Model: F-MLD-C-1FC
Product Series Overview
Standard Multimode Fiber Patch CablesThe F-MLD-C-1FC is a 1 meter graded-index multi-mode fiber optic patch cord with protective jacket and FC connectors at both ends. It is optimized for transmission at 850 and 1300 nm and has a 100 μm core and 140 μm cladding diameter. Cabled patch cords have a 900 μm outer jacket, surrounded by a layer of Kevlar® strands for added strength and protection. An outer PVC cable jacket, 2 mm in diameter, provides additional environmental protection and an operating temperature of -20°C to +80°C.
Related Products
Similar
| Compare | Description | Drawings, CAD & Specs | Avail. | Price | ||
|---|---|---|---|---|---|---|
 | F-MLD-CMultimode Fiber, Graded Index, Jacket, 850/1300 nm, 0.29 NA, 100 µm | |||||
 | F-MLD-C-2SMAFiber Patch Cord, Multimode, F-MLD-C, 850/1300 nm, 2 m, SMA Connectors | |||||
| F-MLD-C-2FCFiber Patch Cord, Multimode, F-MLD-C, 850/1300 nm, 2 m, FC Connectors |
