Research Arc Lamp Housings

Research Arc Lamp Housings allow DC arc lamps to operate with optimum performance while providing a safe operating environment for the user. Choose from a wide selection of lamp wattages, condensing lens types, and flange sizes. By choosing a lamp housing that meets their wavelength output and output beam characteristic requirements, users are choosing a versatile component capable of operating many of the DC Arc Lamps that are sold separately.

Built-in ignitor and rear reflector
Simple lamp alignment process
Integrated lamp cooling fan and safety interlock feature
Three different lens types used in condensing lens configurations
Three different flange sizes available
Interchangeable lamps

See All Features

Description	Compatibility	Avail.	Price
6177 Research Arc Lamp HousingsLamp Socket Adapter, 1600 W Xe Ozone Free Lamp	UNIVERSAL	Discontinued
66901 Research Arc Lamp HousingsArc Lamp Housing, Research, 50-500 W, F/1.5 Plano-Convex, 1.5 Inch Flange	UNIVERSAL		$3,640
66902 Research Arc Lamp HousingsArc Lamp Housing, Research, 50-500 W, F/1 2 Element Plano-Convex, 1.5 Inch Flange	UNIVERSAL		$3,745
66905 Research Arc Lamp HousingsArc Lamp Housing, Research, 50-500 W, F/0.7 4 Element Aspherab, 3 Inch Flange	UNIVERSAL	Discontinued
66921 Research Arc Lamp HousingsArc Lamp Housing, Research, 450-1000 W, F/1 2 Element Plano-Convex, 2 Inch Flange	UNIVERSAL		$5,740
66923 Research Arc Lamp HousingsArc Lamp Housing, Research, 450-1000 W, F/0.7, 4 Element Aspherab, 3 Inch Flange	UNIVERSAL		$9,885
67001 Research Arc Lamp HousingsArc Lamp Housing, Research, 50-500 W, F/2.2 Asphere, 1.5 Inch Flange	UNIVERSAL		$4,180
67003 Research Arc Lamp HousingsResearch Arc Lamp Housing, 50-500W, F/2.2, Asphere, Focused, 1.5 In	UNIVERSAL	Discontinued
67005 Research Arc Lamp HousingsArc Lamp Housing, Research, 50-500 W, F/1 Asphere, 1.5 Inch Flange	UNIVERSAL		$4,245

Compatibility

Light Source Components Compatible with 50 - 500 W Research Arc Lamp Housings

Lamp Type	Lamp Model	Lamp Socket Adapter	Power Supply	Cable	Complete System
Xenon	6251NS	66150	69907	70050	Low Power Xe
	6263
	6257
	6255	66151
	6254	66151
	6256	66152	69907	70050	-
	6259	66160	69911	70050	Medium Power Xe
	6258	66160	69911	70050	Medium Power Xe
Mercury	6282	66158	69907	70051	Low Power Hg
	6281	66150	69907	70051	-
	6283NS	66144	69910	70051	Medium Power Hg
	6286	66161
	6285	66162
Mercury-Xenon	6290	66169	69911	70050	Medium Power Hg-Xe
	6291	66152
	66142	66159

Light Source Components Compatible with 450 - 1000 W Research Arc Lamp Housings

Lamp Type	Lamp Model	Lamp Socket Adapter	Power Supply	Cable	Complete System
Xenon	6279NS	6163	69920	70052*	High Power Xe
	6278	6163
	6271	6162
	6269	6162
Mercury-Xenon	66142	6379	69920	70052*	High Power Hg-Xe
	6293	6162
	6295NS	6162
*70052 cable set is included in 69921 and 69923 housing.

Features

Simple Lamp Alignment Process

Due to small manufacturing differences between lamps, the rear reflector position and lamp position relative to the condenser lens must be adjusted when a new lamp is installed in the housing. Adjustment knobs located on the exterior of the lamp housing allow for optimum positioning of the lamp and rear reflector.

Rear Reflector for Increased Light Output

A rear reflector is built into the lamp housing to collect back scatter from the lamp that would otherwise be lost. An estimated 60% increase in output intensity from the lamp housing is observed due to this rear reflector. Due to small manufacturing differences between lamps, the rear reflector needs to be adjusted when a new lamp is installed.

Integrated Lamp Cooling Fan and Safety Interlock Feature

A temperature sensor inside the lamp housing monitors the lamp's operating temperature and controls the cooling fan accordingly. This keeps the lamp at a safe temperature for operation and ensures the temperature required for proper wavelength emission of the lamp is maintained. The Research Lamp Housing also includes as Safety Interlock Feature. If the lamp housing door or interconnection cable to the power supply are not firmly secured, the lamp will not ignite or voltage supply to the lamp will cease. This protects the user from accidental exposure to UV radiation and high voltage.

Built-in Ignitor

Starting an arc lamp requires a pulse ranging from several hundred to several thousands of volts to excite the gas between the lamp's electrodes. An ignitor is built into the lamp housing to meet this requirement.

Three Different Flange Sizes Available

Output flanges of 1.5 inches, 2 inches, and 3 inches are coupled to the output of these Research Lamp Housings. The output flange size determines the diameter of the collimated output beam and should also be considered based on what component the lamp housing will be coupled to. Flange couplers and adaptors for interchanging between different flange sizes are offered if this is required to couple the lamp housing to a monochromator or other piece of equipment.

Interchangeable Lamps

Oriel^® offers Research Lamp Housings capable of operating two different ranges of lamp wattages: 50 to 500 W and 450 to 1000 W. All Xenon, Mercury-Xenon, and Mercury arc lamps can be operated in the lamp housing that matches their lamp wattage. The appropriate socket adapter, Lamp Housing Interconnection Cable, and Arc Lamp Power Supply is also necessary to operate the lamp. Check out the Compatibility guide below for more information.

Three Different Lens Types Used

Oriel uses three different types of lenses to use in Condenser Lens configurations. These lens types differ in cost and quality of output beam collimation quality:

Plano Convex: Most economic lens option, utilizes an asymmetric lens shape to minimize spherical aberration
Aspheric: The front surface of an aspheric lens gradually changes in curvature from the center of the lens to the edge. This shape reduces spherical aberration more effectively than a Plano Convex Lens
Aspherab™: This lens configuration provides the highest quality output light. Four different lenses are used in a unique configuration to provide light output that is nearly free from spherical aberration.

Condenser lens assemblies also differ in f/#. A smaller f/# means the lens is placed closer to the light source inside the lamp housing. This allows for greater radiant flux as more light is collected by the lens. However, this also causes greater lens aberration. As a result, more light does not mean more quality light. Higher f/#'s are suggested if a high quality collimated beam is needed from the output of the lamp housing. However, lower f/#'s are suggested for coupling to a monochromator due to their higher throughput. The output wavelength required from the lamp should also be considered when choosing a lamp housing.

Arc Lamp Safety

Arc lamps may emit dangerous levels of UV radiation depending on their source type. Ensure that only authorized personnel are in the vicinity of the source, and wearing the necessary safety equipment such as UV protective eyewear, clothing, and gloves. Lighted UV warning signs, posted outside laboratory doors where UV sources are operating, can prevent accidental exposure. Newport also recommends using an electronic shutter to block the beam when the source is not in use but remains turned on. Alternatively, the beam can be safely contained by using beam tubes or fiber optic cables to deliver the light to a sample. It is recommended to vent the ozone that is produced by some lamp models to the outside or use the 66087 Ozone Eater.

Accessories

Digital Exposure System

For further intensity control, enhanced light stability, and timed exposures:

	Compare	Description	Compatibility	Drawings, CAD & Specs	Avail.	Price
		68950 Digital Exposure System, Research Lamp Sources	UNIVERSAL			$6,820
		68952 Adapter Kit, Research Lamp Housing to Light Intensity Controller/Timer	UNIVERSAL			$315

Safety Equipment

Description	Compatibility	Price
49121 Ultraviolet Protective Gloves, Size 10, Black Neoprene, Set of 3	UNIVERSAL	$75
49123 UV Protective Gloves, Size 8, Black Neoprene, Set of 3	UNIVERSAL	$75
49126 Safety Goggles, UV Light Sources, Flexible Frame	UNIVERSAL	$80
66087 Ozone Eater™, 110/220 VAC, 50/60 Hz	UNIVERSAL	$2,090
