Arc Lamp Power Supply, Universal, 350 to 1000 Watt

The 69920 Universal Arc Lamp Power Supply is used to power 450 W and 1000 W solar simulators and light source kits. It is highly regulated and maintains a very stable light output. For long-term stability-critical applications, the Digital Exposure Systems are recommended. It compensates for factors beyond the power supply’s control, such as lamp aging, electrode erosion, and gas absorption. The 69920 has an RS-232 computer interface in order to set the lamp operating parameters, monitor the light output levels, and turn power on/off remotely.

Specifications

Technical Specs

Lamp Wattage
350 - 1000 W (Recommended)
350 - 1200 W (Maximum)
Operating Mode
Constant Power or Constant Current
Light Ripple
< 1% RMS
Digital Meter Resolution, Current
0.1 A
Digital Meter Resolution, Power
1 W
Digital Meter Resolution, Voltage
0.1 VDC
Accuracy
< 0.1% (% full scale)

Power Requirements
95 - 264 VAC, 47 - 63 Hz
Operating Temperature
10 - 40°C
Safety Interlock Voltage
12 VDC/GND
Input Circuit Breaker
12 A, 2 Pole
Dimensions
16.0 x 12.0 x 5.18 inch [406 x 305 x 131.6 mm] (L x W x H)
Weight
20 lbs. [9 kg]

Lamp Wattage
350 - 1000 W (Recommended)
350 - 1200 W (Maximum)
Operating Mode
Constant Power or Constant Current
Light Ripple
< 1% RMS
Digital Meter Resolution, Current
0.1 A
Digital Meter Resolution, Power
1 W
Digital Meter Resolution, Voltage
0.1 VDC
Accuracy
< 0.1% (% full scale)

Power Requirements
95 - 264 VAC, 47 - 63 Hz
Operating Temperature
10 - 40°C
Safety Interlock Voltage
12 VDC/GND
Input Circuit Breaker
12 A, 2 Pole
Dimensions
16.0 x 12.0 x 5.18 inch [406 x 305 x 131.6 mm] (L x W x H)
Weight
20 lbs. [9 kg]
