Mounting Plate, Cornerstone 130B Monochromator

The 74006 Mounting Plate is used to secure a Cornerstone 130B Monochromator to an inch or metric optical table. The ability to mount the monochromator simplifies setup and alignment of the optical system. The mounting plate also helps ensure consistent results over time, as the monochromator cannot be accidentally moved out of position. The plate adds 0.25 inch [6.35 mm] to the optical height.
This plate can also be used with the legacy Cornerstone 130 series monochromators.
If the Cornerstone 130B will be used with Oriel® research lamp housing, consider using the 74017 mounting kit.
