Optical Post Lab Jack, 3 mm Travel, 4.4 N Load, M4 Thread
The 9201-M Tiny Lab Jack simplifies the alignment of small-area detectors. It gives you 1/8 in. of travel with 0.001 in. resolution. Threaded M4 holes on the top and bottom let you mount it directly to a post or pedestal. A single setscrew locks the jack solidly.
