Cable, Filter Wheel to CS130B, CS260B and MS260i Spectroscopy Instruments

The CBL-CSMS-FW is a ribbon cable used to connect a filter wheel to the Oriel^® CS130B and CS260B monochromators, as well as the legacy MS260i imaging spectrograph and legacy Cornerstone CS130 and CS260 models. The instrument provides power as well as control to the filter wheel. This ribbon cable is compatible with filter wheel models 74010, 74041, and USFW-100.

Specifications

Technical Specs

Type
Ribbon Cable

Type
Ribbon Cable
