Pedestal Mounting Base, 38.1 mm Diameter Posts, M6 Thread

The M-SR-B Non-magnetic Pedestal Base is used when pedestal mounting is needed but without the magnetic base. The M-SR-B pedestal base can be combined with the M-SR-E extension posts and SP-S spacers for various height applications. The SR-F, all-stainless steel clamping fork, is used to clamp the M-SR-B on to an optical table.

Specifications

Technical Specs

Type
Pedestal Base Adapter
Height
12.7 mm

Material
Stainless Steel
Diameter
38.1 mm

Type
Pedestal Base Adapter
Height
12.7 mm

Material
Stainless Steel
Diameter
38.1 mm

Resources & Downloads

3D Product Models

2D Product Drawings

SR-B-303(69.3 kB, PDF)

Other

M-SR-B RoHS Certificate(276.8 kB, PDF)
M-SR-B_RoHS2021.pdf(677.3 kB, PDF)
