Fiber-Optic Receiver, DC Coupled, 800-1650 nm, 12 GHz, FC Singlemode
The 1544-B DC-Coupled NIR Fiber-Optic Receiver is ideal for applications that require high sensitivity, high speed, and clean responses. It offers clean responses and 32-ps rise times making it well-suited for time-domain characterization of 10-Gbit/s components. Its high gain and well-behaved frequency response also make it useful for frequency-domain measurements. For higher responsivity from 800-1650 nm, this photoreceiver has a singlemode fiber input and consists of our new, improved InGaAs PIN photodiodes followed by a GaAs HBT amplifier.
An external power supply, which must be purchased separately, is required – we recommend our
Resources & Downloads
Drawings And Cad
15xx-B Drawing.pdf(401.2 kB, PDF)
Other
RoHS Declaration - 10x4 14x4 15x4 Detectors.pdf(353.2 kB, PDF) CE Declaration 1580-B 1544-B 1544-B-50.pdf(236.5 kB, PDF)
Related Products
Accessories (sold separately)
| Compare | Description | Drawings, CAD & Specs | Avail. | Price | ||
|---|---|---|---|---|---|---|
 | 0901Lab Power Supply, ±15 VDC | |||||
 | 0923-2Accessory Cable, Pico (m8) Double-Ended, Male to Male, 2 m | |||||
 | 1226Connector Adapter, Female SMA to Male BNC | |||||
 | 1227NFFlexible Cable, 40 GHz, Wiltron K Male to Female, 24 in. Length | |||||
 | F-SY-C-1FCFiber Patch Cord, Singlemode, 980-1550 nm, F-SY-C, 1m, FC/UPC Connectors. | |||||
| F-SMF-28-C-1FCFiber Patch Cord, Singlemode, 1310/1550nm, F-SMF-28-C, 1m, FC/UPC Connectors |
