Miniature Optical Post Mounting Accessories
Miniature Optical Post Mounting Accessories
Our miniature optical post clamps, collars, and filter mounts complement our TSP Series 0.31 in. (7.9 mm) diameter stainless steel miniature posts to provide customization of compact optical systems.
- Clamps and collars for miniature optical posts
- Held in place with set screw or knob
- Right angle and adjustable optical post clamps See All Features
| Compare | Description | Drawings, CAD & Specs | Avail. | Price | ||
|---|---|---|---|---|---|---|
 | C-0.3 Miniature Post Mounting AccessoriesPost Collar, 0.313 in. Diameter Optical Posts | |||||
 | M-MCA-1 Miniature Post Mounting AccessoriesRight-Angle Post Clamp, 7.9 mm Diameter Optical Posts, M4 Thread | |||||
 | M-MCA-2 Miniature Post Mounting AccessoriesAdjustable-Angle Post Clamp, 8 mm Diameter Optical Posts | |||||
 | M-MFC-1 Miniature Post Mounting AccessoriesOptical Filter Clamp, 7.9 mm Diameter Optical Posts, M4 Thread | |||||
 | MCA-1 Miniature Post Mounting AccessoriesRight-Angle Post Clamp, 0.313 in. Diameter Optical Posts, 8-32 Thread | |||||
 | MCA-2 Miniature Post Mounting AccessoriesAdjustable-Angle Post Clamp, 0.313 in. Diameter Optical Posts | |||||
 | MFC-1 Miniature Post Mounting AccessoriesOptical Filter Clamp, 0.313 in. Diameter Optical Posts, 8/32 Thread |
Features
Optical Post Collars
Optical post collars provide an index point for a specific post height, allowing an optical post to be removed from an optical post holder and returned to the same height. They can also be used to rotate an optical post while keeping it's height constant. Newport's C-0.3 open-ring post collar for miniature optical posts allows it to be added without having to remove the post from the post holder.
The Miniature C-0.3 and Standard C-0.5 Optical Post Collars shown mounted to MSP and SP Series Optical Posts
Optical Post Clamps
MCA-1 Right-Angle Optical Post Clamps mount two MSP Series optical posts, respectively, at 90° to each other. The clamping screws permit fast, secure post mounting with only moderate finger pressure.
MCA-2 Adjustable-Angle Post Clamps hold two MSP Series Posts, respectively, at an arbitrary angle with respect to each other. Both posts are tightened simultaneously with the knurled knob.
Optical Filter Post Mounts
The MFC-1 Filter Clamp is convenient for holding thin objects such as optical filters, transparencies or even razor blades used as knife edges. An 8-32 (M4) set screw may be threaded into the Delrin clamp for attachment to the end of an MSP Series optical post.
Accessories
0.31 in to 0.5 in Post Clamp
| Compare | Description | Drawings, CAD & Specs | Avail. | Price | ||
|---|---|---|---|---|---|---|
 | RA-0508 Optical Post Clamp, Right-Angle, 0.5 in to 0.31 in Diameter Posts |
